Automatic Horizontal Glass Grinding Line For Building Glass

Reliable Glass Processing Solution

Horizontal Glass Grinding Line is a full-automatic continuous processing line for flat architectural glass. It integrates rough grinding, fine grinding and mirror polishing in one horizontal assembly line. With stable synchronous conveying system and multi grinding heads, it realizes one-pass edge finishing with smooth scratch-free edges. Widely used to process window, curtain wall, shower door, tempered and Low-E glass for large glass deep-processing factories.

Product Highlights

High Efficiency Horizontal Glass Grinding Line Low Scrap Rate Main Advantages:
1.Ultra-high continuous production efficiency:Horizontal linear layout realizes non-stop automatic processing, far higher hourly output than single independent edging machines, perfectly matching large-scale mass production demand.
2.Consistent high-quality polishing effect:Multi-stage grinding technology removes all burrs and sharp corners, delivering uniform mirror bright edges; horizontal flat placement avoids glass surface scratch during grinding.
3.Wide processing compatibility:Adjustable processing range adapts various glass sizes and thickness, supports straight edge, 0–45° chamfer and pencil edge, covers all architectural flat glass processing needs.
4.Low operation cost & material loss:Closed water circulation system saves water consumption; anti-vibration structure greatly reduces glass breakage rate, cutting raw material loss cost for factories.
Intelligent automatic operation:Servo automatic width adjustment and visual touch control; workers only need simple parameter setting, lower labor dependence and training cost.
5.Flexible line expansion:Reserved docking interface to connect glass washing machine, drilling machine and loading/unloading equipment, forming full automatic glass deep processing production line.
Stable durable & easy maintenance:Integrated heavy welded frame reduces vibration; modular grinding head design enables fast wheel replacement and daily cleaning maintenance.

Certifications & Standards

EAC

ISO9001

OEM/ODM

Model Specifications

Model	Max Glass Size	Glass Thickness	Processing Speed	Total Power	Machine Dimension	Machine Weight
Glass edging machines	2500/4000MM	3-19MM	1-8M、MIN	45KW	Glass Bilateral Machines	Glass grinding lines

* Specifications subject to change without notice. Contact our sales team for the latest technical data and custom configurations.

Suitable Applications

Architectural Glass

For doors, windows, facades and curtain wall glass.

Mirror Glass

Suitable for mirror and decorative glass processing.

Furniture Glass

Table glass, cabinet glass and interior glass.

Industrial Glass

Supports customized glass cutting production.

Why Choose Jori?

Trusted by glass factories and engineering companies in over 20 countries worldwide.

Certified Quality

CE, EAC & ISO9001 certified for smooth customs clearance in global markets.

OEM

OEM / ODM Support

Flexible customization with 8 independent production lines and dedicated R&D team.

20+

Years Experience

Over 20 years of technical accumulation in glass processing machinery manufacturing.

24/7

After-Sales Service

Full technical support, installation guidance, spare parts and warranty coverage.
