Vertical and horizontal glass washing machines are crucial to the glass fabrication process to ensure clean, high-quality glass from low-E glass to insulated glass, tempered glass, and much more. The washers are designed to remove any impurities from the sheet to prepare the flat glass for the remaining steps in the manufacturing process, such as tempering or lamination. JORI offer both vertical and horizontal washers that range from entry-level to highly automated (all customizable) to best fit your current and future production needs.
JORI Glass Machine Vertical Glass Washers
JORI Glass Machine is the leading manufacturer of horizontal and vertical glass washing machines. This second-generation family-run business produces glass processing machines featuring the latest technology for efficient glass washing and drying. Some of JORI glass washing machine options that our JORI team carries include:
JORI Glass Machine Top Vertical Glass Washer
JORI Glass Machine Top Vertical Glass Washing Machine elevates the expectations of a basic glass washer in that it’s:
Designed for those who need a machine for efficient washing and drying with low investment and increased reliability
Offers a generous amount of stainless steel in all wet and drying areas
Has customizable lengths for conveyors and delivering performance suitable for heavy glass fabrication and insulated glass production.
JORI Vertical Glass Washing Machine
JORI Vertical Glass Washer comes in a wide range of sizes to meet your glass processing needs and is perfect for stand-alone or inline washing requirements. It is a more automated version of the Top design, which allows it to offer the following benefits:
Automated options for maintaining water cleanliness
A simple move oif the brush drives to the top of the machine increases the reliability and longevity of the machine
It automatically adjusts brushes, air knives and drive rollers for on-the-fly glass thickness adjustments.
JORI High productivity Vertical Glass Washer: The Wave Series of glasswashers from JORI feature sound construction aimed at ensuring maximum reliability and longevity. These JORI vertical glass washing machines are fully automated and offers superior performance in handling all glass processing applications, including the following:
JORI Horizontal Glass Washing Machine
The Italian glass machines company, JORI, manufactures top-of-the-line edgers and horizontal washers for industrial glass processing operations, both large and small. Make your glass fabrication business more efficient using one of the following JORI horizontal glass washing machines:
JORI Horizontal Glass Washer
Glass Washing Machine was designed for those who need a horizontal machine for efficient washing and drying with low investment and increased reliability, for production contexts which do not require particularly high performances or boosted automation. Some unit features include:
A strong construction with a wide use of stainless steel to ensure long-lasting reliability. Fans under the structure that ensure a constant flow of clean air for drying. It is available in a range of 1300mm (51”) to 3300mm (129”) maximum glass size. This horizontal glass washer is especially intended for users who need:
Horizontal Washing Machines Vs Vertical Glass Washing Machines
Not sure which type of washing machine is right for your glass fabrication business? Here’s what you need to know about horizontal and vertical glass washers:
Horizontal Glass Washing Machines – These are the most popular washing machine in the flat glass fabrication industry because they are standalone machines. Typically, horizontal glass washing machines are used for glass which was produced using horizontal processes for edging or glass drilling. This process greatly reduces the risk of scratching or damaging the glass by eliminating the need to manually handle the glass to complete the washing process.
Vertical Glass Washing Machines – Vertical glass washing machines are configured with separate areas of the machine being dedicated to washing and another for drying. Vertical washers are typically used for insulated glass production processes and vertical drilling or CNC working lines. The machine uses high-quality brushes to wash the glass sheet before it goes through the dryer. Vertical washers are common in glass factories that have a limited amount of space.
Tips For Finding The Right Industrial Flat Glass Washer For You
Aside from knowing if a vertical or horizontal washer will work best for your fabrication needs, here are some other things you will want to take into consideration before making your purchase:
Size of Glass Washing Machines
The size of the glass you will be using during the process is one of the first things you should think about when it comes to purchasing a flat glass washing machine. We recommend choosing a machine based on the width of the short side of the glass. You should also be aware of the amount of space you will have in the loading and unloading zones. If you will often have long pieces of glass needing to go through the machine, it is important there will be enough room to safely maneuver the glass before and after washing.
Glass Fabrication Washers’ Drying Process
The drying process of the machine you choose may be sponges or air knives. Washing machines utilizing the air knives drying technology tend to sell more throughout the industry. The air knives process typically dries glass better and requires less maintenance. Unfortunately, these machines are often very loud. To decrease the noise, some glass fabricators will opt for a machine that uses sponge drying. This involves sponge rollers that absorb the water as the glass is squeezed and passed through the dryer. The glass will also pass through an air dryer that blows the remaining water from the surface of the glass.
Budget Consideration When Buying Glass Washing Machines
Anytime you are considering making a large investment for your glass fabrication company, you should consider your budget. To inquire about the pricing and availability of the Neptun washers we have to offer, please contact us. Our friendly, knowledgeable staff and sales team will happily answer any questions you may have and provide guidance on the glass washing machine that will best meet your needs.
Applications for Flat Glass Washing Machines
Flat glass washing machines are a vital part of ensuring product quality, efficiency, and reliability in modern glass production. While these are some of the most common applications, their versatility means they can be adapted to many other specialized processes within the glass industry.
Architectural Glazing & Curtain Walls
Before glass is tempered, coated, or laminated for commercial storefronts or building facades, it must be free of dust, debris, and surface films. Flat glass washing machines provide the precision cleaning needed to achieve flawless visual clarity and structural reliability.
Insulated Glass Unit (IGU) Production
Clean, contaminant-free glass is critical for ensuring a strong, long-lasting seal. Flat glass washing machines remove particles and residues that could compromise thermal performance or lead to premature seal failure.
Low-E and Solar Control Glass
Specialty coatings require careful handling to preserve energy-efficient properties. Controlled washing processes protect these coatings while maintaining surface integrity.
